Specifications |
|
Machine
Features |
| |
|
|
|
Saw Capacity |
|
Standard Features |
|
Round |
1.18" - 11.8" |
|
-
Motion Detector |
|
Square |
N/A |
|
- Variable Blade Speed |
|
Rect (W x H) |
N/A |
|
- Shaftless Chip Conveyor |
|
Max. Load |
5,750 lbs |
|
- Automatic Trim Cut - Set
Range 0.40"- 1.57" |
|
Saw Blade |
|
- Blade Deviation Monitor |
|
Speed
(fpm) |
50 -400 |
|
- Automatic Guide Arm
Positioning |
|
Size |
16'5" x 1 1/2" x .050 |
|
- Full Stroke Vising |
|
Motor Output |
|
- 1/8 hp Wire Brush Motor |
|
Blade Drive |
5 hp |
|
- 1/16 hp Roller Positioning
Motor |
|
Hydraulic |
2 hp |
|
- 1/2 hp Front Vise Motor |
|
Coolant |
1/4 hp |
|
- Feed Length 0.400" - 19' 7" |
|
Fluid Capacity |
|
- 20' Maximum Material Length*
( See Below ) |
|
Hydraulic |
16.3 gal |
|
- Material Positioning
Accuracy +/- 0.004" Per Index |
|
Coolant |
29 gal |
|
- Allowable Material
Distortion .078" Per 40" |
|
Mach. Weight |
|
- 59" Loading Table Width |
|
Gross
(lbs) |
17,777 lbs |
|
- Piece Quantity Per Station 0
- 999 |
|
Dimensions |
|
Optional Accessories |
|
Table Height |
28.3" |
|
- Vibratory Marking |
|
Floor Space |
133.1W x 357.5 L |
|
* Customer Required Infeed & Outfeed
Lengths Greater than |
|
Max. Height |
N/A |
|
20' Maximum
Machine Standard Can Be Accommodated |
